Trykkluftassistert åndedrettsvern

3M™ Speedglas™ Sveiseskjerm 9100 FX uten sveiseglass, men med hodeinnredning.

SUNDSTRØM

Vippbar løsning med stort buet visir (17 x 10 cm) gir bedre sidesyn. Versaflo Trykkluftregulator V-500E er en balansert regulator som bæres i beltet og er enkel å justere. Med den pålitelige regulatoren får du alltid luftstrømmen du velger – fra 170 til 305 liter i minuttet. Luften som tilføres, må være av god pusteluftkvalitet og oppfylle kravene i EN 12021. Oljedamp, vanndamp eller ikke-giftig ubehagelig lukt i lufttilførselen kan fjernes med en luftrensestasjon, for eksempel 3M™ Filtreringssystem ACU-1 og ACU-2. Med riktig type filter gir Adflo Batteriturbo effektiv beskyttelse mot både partikler og gasser – alt i ett system

CLEAN AIR TRYKKLUFTSYSTEM

Compressed air-fed full mask with excellent fit, high protective effect and very good breathing comfort for the toughest areas of use. Polycarbonate visor. With filter back-up intended to be connected to a suitable compressed air source with breathable air. The overpressure that then occurs in the mask prevents the surrounding polluted air from reaching the user. The breathing tube can also be removed from the mask and it can then be used as a clean filter cover. Can be used as an alternative to filter protection in all situations where such is recommended. This applies in particular to heavy or long-term work and when the contaminants have poor warning properties or are particularly toxic. Made of materials that do not cause sparks during friction, which enables use in explosive/flammable environments. The control valve is equipped with a warning whistle that gives a signal if the amount of air falls below the recommended amount. The compressed air should be cleaned with a compressed air filter type Sundströms SR 99-1.
Contents: Full face mask with breathing hose and polycarbonate visor, control valve, belt, screw cap, cover cap, pre-filter holder, flow meter, filter adapter and user manual.< BR> Working pressure: 5-7 bar
Air flow: 150-320 l/min
Operating temperature: -10°C - +55°C
Assigned protection factor: 1000 (4A, 4B)
Nominal protection factor: 2000 (4A, 4B)
Weight: 750 g (without control valve)

Approved/Certified according to:
EN 14594:2005

(HTML text not available)

(HTML text not available)

The ACU Aircare filter panel is connected to the compressed air system as an outlet for users so that the breathing air is filtered and achieves a good air quality that is suitable for breathing. Aircare is delivered either as a free-standing or wall-mounted panel and has 3 different filters. The first filter is a cyclone filter that separates large particles and droplets. The next filter is a coalescing filter that separates smaller dust and liquid particles. The last blanket is a carbon filter that mainly separates oil vapors.
NOTE! Not all types of gases/vapours can be filtered, see user manual for more information. The air from the Aircare panel can be used as breathing air, but also for, for example, spray guns. When using the Flowstream regulator (without connected air tools), up to 3 users may be connected to the filter panel. When Vortemp/Vortex or air tools are used, only one may users are connected to the filter panel. The regulator on the Aircare panel can adjust the pressure out between 0-10 bar and the panel is delivered without connectors, but with 3/8 in. thread on inlet and outlet.
The picture shows a free-standing air purification station.
